The DL type hydraulic die lifter is modeled by hydraulic pressure and has a strong die-lifting ability, which is suitable for use when the die weight variation is large.
>> 规格特性
DL-22
|
型号 |
总长度 |
滚轮数 |
载模能力 |
油压缸 (kg) |
|
|
丁数 |
举模力 |
||||
|
DL-22-300 |
300 | 5 | 300 | 2 | 500 |
|
DL-22-400 |
400 | 7 | 420 | 3 | 750 |
|
DL-22-500 |
500 | 9 | 540 | 4 | 1000 |
|
DL-22-600 |
600 | 11 | 660 | 5 | 1250 |
|
DL-22-700 |
700 | 13 | 780 | 5 | 1250 |
|
DL-22-800 |
800 | 15 | 900 | 6 | 1500 |
|
型号 |
油压缸距离 (mm) |
||||
| P1 | P2 | P3 | P4 | P5 | |
|
DL-22-300 |
200 |
|
|
|
|
|
DL-22-400 |
90 | 210 |
|
|
|
|
DL-22-500 |
90 | 220 | 90 |
|
|
|
DL-22-600 |
90 | 160 | 160 | 90 |
|
|
DL-22-700 |
90 | 210 | 210 | 90 |
|
|
DL-22-800 |
90 | 220 | 220 | 150 | 90 |
